Newton Fiber Cable Management

Horizontal or Vertical?.

Newton Fiber Cable Management is used to house and organize Fiber cabling vertically and horizontally on or above equipment Racks and Frames.

Fiber Channel

00250400CA Fiber Channel
00250300CA Fiber Channel
00250200CA Fiber Channel
Solid Fiber Channel
Part Number Description Color Pre-drilled
00250100CA 2x2 Solid Orange No
00250100CB 2x2 Solid Orange Yes
00250100DA 2x2 Solid Yellow No
00250100DB 2x2 Solid Yellow Yes
00250200CA 4x4 Solid Orange No
00250200CB 4x4 Solid Orange Yes
00250200DA 4x4 Solid Yellow No
00250200DB 4x4 Solid Yellow Yes
Slotted Fiber Channel
Part Number Description Color Pre-drilled
00250300CA 2x2 Slotted Orange No
00250300CB 2x2 Slotted Orange Yes
00250300DA 2x2 Slotted Yellow No
00250300DB 2x2 Slotted Yellow Yes
00250400CA 4x4 Slotted Orange No
00250400CB 4x4 Slotted Orange Yes
00250400DA 4x4 Slotted Yellow No
00250400DB 4x4 Slotted Yellow Yes

Fiber Splice

Used to connect two fiber channels.

00250500CA Fiber Duct splice
00252700CA Fitting Splice
Part Number Description Color Pre-drilled
00250500CA 2″x2″ Splice Orange No
00250500CB 2″x2″ Splice Orange Yes
00250500DA 2″x2″ Splice Yellow No
00250500DB 2″x2″ Splice Yellow Yes
00250600CA 4″x4″ Splice Orange No
00250600CB 4″x4″ Splice Orange Yes
00250600DA 4″x4″ Splice Yellow No
00250600DB 4″x4″ Splice Yellow Yes
Part Number Description Color Pre-drilled
00252700CA 2″x2″ Fitting Splice Orange No
00252700CB 2″x2″ Fitting Splice Orange Yes
00252700DA 2″x2″ Fitting Splice Yellow No
00252700DB 2″x2″ Fitting Splice Yellow Yes
00252800CA 4″x4″ Fitting Splice Orange No
00252800CB 4″x4″ Fitting Splice Orange Yes
00252800DA 4″x4″ Fitting Splice Yellow No
00252800DB 4″x4″ Fitting Splice Yellow Yes

Types of Fiber Caps

End Cap
End Cap
End Cap
Part Number Description Color Pre-drilled
00250900CA 2″ x 2″ End cap Orange No
00250900CB 2″ x 2″ End cap Orange Yes
00250900DA 2″ x 2″ End cap Yellow No
00250900DB 2″ x 2″ End cap Yellow Yes
00251000CA 4″ x 4″ End cap Orange No
00251000CB 4″ x 4″ End cap Orange Yes
00251000DA 4″ x 4″ End cap Yellow No
00251000DB 4″ x 4″ End cap Yellow No

Fiber Tee

Used to make a "T" shape at an intersection of fiber channel.

Horizontal Tee
Horizontal Tee
Horizontal Tee
Horizontal Tee with lid removed
Horizontal Tee
Part Number Description Color Pre-drilled
00251500CA 2″x2″ Horiz. Tee Orange No
00251500CB 2″x2″ Horiz. Tee Orange Yes
00251500DA 2″x2″ Horiz. Tee Yellow No
00251500DB 2″x2″ Horiz. Tee Yellow Yes
00251600CA 4″x4″ Horiz. Tee Orange No
00251600CB 4″x4″ Horiz. Tee Orange Yes
00251600DA 4″x4″ Horiz. Tee Yellow No
00251600DB 4″x4″ Horiz. Tee Yellow Yes
00261500DA 4″x8″ Horiz. Tee Yellow No
Vertical Tee
Part Number Description Color Pre-drilled
00251700CA 2″x2″ Vert. Tee Orange No
00251700CB 2″x2″ Vert. Tee Orange Yes
00251700DA 2″x2″ Vert. Tee Yellow No
00251700DB 2″x2″ Vert. Tee Yellow Yes
00251800CA 4″ x 4″ Vert. Tee Orange No
00251800CB 4″ x 4″ Vert. Tee Orange Yes
00251800DA 4″ x 4″ Vert. Tee Yellow No
00251800DB 4″ x 4″ Vert. Tee Yellow Yes
00251701DB 2″ x 2″ Down Spout Yellow Yes
Horizontal & Vertical Tee with Reducer
Part Number Description Color Pre-drilled
00253600CA 4″x4″ Vert. Tee with 2″x2″ outlet Orange No
00253600CB 4″x4″ Vert. Tee with 2″x2″ outlet Orange Yes
00253600DA 4″x4″ Vert. Tee with 2″x2″ outlet Yellow No
00253600DB 4″x4″ Vert. Tee with 2″x2″ outlet Yellow Yes
00253700CA 4″x4″ Horiz.Tee with 2″x2″ outlets Orange No
00253700CB 4″x4″ Horiz.Tee with 2″x2″ outlets Orange Yes
00253700DA 4″x4″ Horiz.Tee with 2″x2″ outlets Yellow No
00253700DB 4″x4″ Horiz.Tee with 2″x2″ outlets Yellow Yes

Fiber Reducers

Going from Bigger to smaller

Fiber Channel Reducer
Fiber Channel Reducer
Fiber Channel Reducer
Horizontal Tee
Part Number Description Color Pre-drilled
00250800CA 4″ to 2″ Reducer Orange No
00250800CB 4″ to 2″ Reducer Orange Yes
00250800DA 4″ to 2″ Reducer Yellow No
00250800DB 4″ to 2″ Reducer Yellow Yes

Fiber Cross junction

Used to make a "X" shape at an intersection of fiber channels.

4-way Cross
4-way Cross with lid removed
4-way Cross Opening
4-way Cross interior
4-Way Cross
Part Number Description Color Pre-drilled
00251100CA 2″x2″ 4-way Cross Orange No
00251100CB 2″x2″ 4-way Cross Orange Yes
00251100DA 2″x2″ 4-way Cross Yellow No
00251100DB 2″x2″ 4-way Cross Yellow Yes
00251200CA 4″x4″ 4-way Cross Orange No
00251200CB 4″x4″ 4-way Cross Orange Yes
00251200DA 4″x4″ 4-way Cross Yellow No
00251200DB 4″x4″ 4-way Cross Yellow Yes

Types of Fiber Elbows

Horizontal Elbow Fiber connector
Horizontal Elbow Fiber connector
Vertical Down Elbow Fiber connector
Vertical Down Elbow Fiber connector
90° Horizontal Elbow
Part Number Description Color Pre-drilled
00251300CA 2″x2″ Horz. Elbow Orange No
00251300CB 2″x2″ Horz. Elbow Orange Yes
00251300DA 2″x2″ Horz. Elbow Yellow No
00251300DB 2″x2″ Horz. Elbow Yellow Yes
00251400CA 4″x4″ Horz. Elbow Orange No
00251400CB 4″x4″ Horz. Elbow Orange Yes
00251400DA 4″x4″ Horz. Elbow Yellow No
00251400DB 4″x4″ Horz. Elbow Yellow Yes
90° Vertical Down Elbow
Part Number Description Color Pre-drilled
00251900CA 2″x2″ Vert. Down Elbow Orange No
00251900CB 2″x2″ Vert. Down Elbow Orange Yes
00251900DA 2″x2″ Vert. Down Elbow Yellow No
00251900DB 2″x2″ Vert. Down Elbow Yellow Yes
00252000CA 4″x4″ Vert. Down Elbow Orange No
00252000CB 4″x4″ Vert. Down Elbow Orange Yes
00252000DA 4″x4″ Vert. Down Elbow Yellow No
00252000DB 4″x4″ Vert. Down Elbow Yellow Yes
90° Vertical Up Elbow
Part Number Description Color Pre-drilled
00252100CA 2″x2″ Vert. Up Elbow Orange No
00252100CB 2″x2″ Vert. Up Elbow Orange Yes
00252100DA 2″x2″ Vert. Up Elbow Yellow No
00252100DB 2″x2″ Vert. Up Elbow Yellow Yes
00252200CA 4″x4″ Vert. Up Elbow Orange No
00252200CB 4″x4″ Vert. Up Elbow Orange Yes
00252200DA 4″x4″ Vert. Up Elbow Yellow No
00252200DB 4″x4″ Vert. Up Elbow Yellow Yes
45° Vertical Down Elbow
Part Number Description Color Pre-drilled
00252300CA 2″x2″ Vert. Down Elbow Orange No
00252300CB 2″x2″ Vert. Down Elbow Orange Yes
00252300DA 2″x2″ Vert. Down Elbow Yellow No
00252300DB 2″x2″ Vert. Down Elbow Yellow Yes
00252400CA 4″x4″ Vert. Down Elbow Orange No
00252400CB 4″x4″ Vert. Down Elbow Orange Yes
00252400DA 4″x4″ Vert. Down Elbow Yellow No
00252400DB 4″x4″ Vert. Down Elbow Yellow Yes
45° Vertical Up Elbow
Part Number Description Color Pre-drilled
00252500CA 2″x2″ Vert. Up Elbow Orange No
00252500CB 2″x2″ Vert. Up Elbow Orange Yes
00252500DA 2″x2″ Vert. Up Elbow Yellow No
00252500DB 2″x2″ Vert. Up Elbow Yellow Yes
00252600CA 4″x4″ Vert. Up Elbow Orange No
00252600CB 4″x4″ Vert. Up Elbow Orange Yes
00252600DA 4″x4″ Vert. Up Elbow Yellow No
00252600DB 4″x4″ Vert. Up Elbow Yellow Yes

Types of Fiber Down Spots and Exits

Instant Exit
Down Spout
Entry Fitting
Trumpet
Instant Exit
Part Number Description Color Pre-drilled
21996040CB 4″x 4″ Instant Exit Yellow --
21996004DB 4″x 4″ Instant Exit Yellow yes
Entry fitting
Part Number Description Color Pre-drilled
21739001CA 2″x2″ Entry fitting Yellow --
21739000CA 4″x4″ Entry fitting Yellow --
21739000DB 4″x4″ Entry fitting Yellow Yes
Trumpet fitting
Part Number Description Color Pre-drilled
00254600CA 2″x2″ Trumpet Orange No
00254700CA 4″x4″ Trumpet Orange No
00254700CB 4″x4″ Trumpet Orange Yes

Types of Fiber Tubing

Tubing
Adapters
Kits
Tube Kits
Part Number Description Color
00254900CA 2″ Flex tube kit Orange
00254900DA 2″ Flex tube kit Yellow --
00254900DB 2″ Flex tube kit Yellow
Entry fitting
Part Number Description Color Pre-drilled
00253900CA 2″ square to 1.5″ adapter only Orange No
00253900CB 2″ square to 1.5″ adapter only Orange Yes
00253900DA 2″ square to 1.5″ adapter only Yellow No
00253900DB 2″ square to 1.5″ adapter only Yellow Yes
00253901CA 2″ square to 1″ round flex Orange No
00253901CB 2″ square to 1″ round flex Orange Yes
00253901DA 2″ square to 1″ round flex Yellow No
00253901DB 2″ square to 1″ round flex Yellow Yes
00253902CA 4″ square to 2″ round flex Orange No
00253902CB 4″ square to 2″ round flex Orange Yes
00253902DA 4″ square to 2″ round flex Yellow No
00253902DB 4″ square to 2″ round flex Yellow Yes

Types of Fiber Support

Support Kits
Part Number Description
0025420010 Solid Unistrut Channel. 1-5/8″ x 13/16″ x 120″ long, 14 gauge steel.
0025520810 Mounting kit to mount 4″ x 4″ fiber to 5/8″-11 threaded rod with a flat bracket.
0025700145 Cable Retainer 2″ X 2″
0025440010 Junction Kit And Hardware To Create A T Or 90 Degree Junction With 1 5/8″ X 13/16″ Unistrut.
0025540810 Mounting Kit For Securing 4" X 4" Fiber Channel To Auxiliary Framing Channel
Cable Rack Hardware Kits
Part Number Description
0025500310 2" x 2" Fiber Channel Below Cable Rack
0025500410 4" x 4" Fiber Channel Below Cable Rack
0025500510 2" x 2" Fiber Channel Above Cable Rack
0025500610 4" x 4" Fiber Channel Above Cable Rack.
Cable Rack Hardware Kits
Part Number Description
0025510410 mount 5/8″ Unistrut To A Bracket
0025510810 mount 4″ x 4″ Fiber Channel To A Bracket
0025520610 mount 2″ x 2″ Fiber To 5/″8-11 Threaded Rod
0025500610 4″ x 4″ Fiber Channel Above Cable Rack.
Bracket Mounting Kit
Part Number Description
002556011 mount 2″ x 2″ Fiber Channel to 1 5/8" wide Unistrut
0025560210 mount 4″ x 4″ Fiber Channel to 1 5/8" wide Unistrut
0025580110 mount 2″ x 2″ Fiber Channel To The Front Of An Equipment Rack
0025580210 4″ x 4″ Fiber Channel To The Front Of An Equipment Rack
Cable Rack Side Rail Cover
Part Number
22030000BA

An example Illustration of a typical Multi-tier Cable Rack assembly
